Xi lanh SMC CDQ2B40-100DMZ-M9BL
Mã sản phẩm: CDQ2B40-100DMZ-M9BL
Thương hiệu: SMC
Mô tả
| Cylinder (Tube) Inner Diameter(φ) | 40 | Stroke(mm) | 100 |
| Cylinder Operation Method | [Double Acting] Double Acting | Rod Operation Method | Single Rods |
| Main Body Shape | [Block Shape] Block shape | Additional Function | Standard |
| Environment, Applications | Standard | Operating Temperature(°C) | -10～60 |
| End Locking | No | Valves | No |
| Operating Pressure(MPa) | 0.05～1 | Cushion | None |
| Specification | Built-in magnet | First-stage Stroke (Dual Stroke Only) | N/A |
| Port Thread Type | BSPT | Body Options | Standard |
| Auto Switches | M9B | Lead Wire Length(m) | 1 |
| Number of Auto Switches | 2 | Auto Switch Mounting Style | Band Mounting |
| Rod End Bracket | None | Type of Mount Support | Through-hole |
| Rod Tip Shape | Male Thread | Tube Material | Standard |
| Custom-made Specifications | Standard | Specification of cylinder | Standard |
| Sealing materials | N/A | Grease | Standard |
| Mounting bolt | None | Connector Type | None |
| Coil scraper | N/A | Type | Standard |
